Shenzhen Showin Stage Lighting Co., Ltd
2-Way DMX Backup 1024CH DMX512 1990 Optical Isolation HV Protection Cast Aluminum IP65 Weatherproof UV Resist LED Indicator Wide AC88-256V Outdoor Signal Device IP65 DMX Splitter Backup Mode Dual Output DMX Backup Controller 1024 Channel DMX Signal Protector Real-Time Switch for Festival Landscape Lighting
• Cast aluminum & IP65 build with UV resistance, auto backup keeps signals steady for outdoor lighting systems.
• Full isolation and high voltage protection prevent interference, reliable for long-term outdoor operation.
• Super driving capacity plus clear LED indicators for easy signal monitoring in various outdoor venues.
• Universal wide voltage fits global power grids, compact structure for convenient field installation.
Price range: $259.00 through $1,350.00
2-Way DMX Backup 1024CH DMX512 1990 Optical Isolation HV Protection Cast Aluminum IP65 Weatherproof UV Resist LED Indicator Wide AC88-256V Outdoor Signal Device IP65 DMX Splitter Backup Mode Dual Output DMX Backup Controller 1024 Channel DMX Signal Protector Real-Time Switch for Festival Landscape Lighting
DMX 512/1990 Standard.
2 DMX optical isolated outputs (1024 Channels).
BACKUP mode control to ensure the signal is not interrupted.
BACKUP mode: when input 1A DMX- signal fail, input 2A DMX- signal take over immediately. When input 1B DMX- signal fail, input 2B DMX- signal take over immediately.
100% electrical isolation between all in/outputs: problems on 1 port will not influence the other ports.
Input and output ports use High Voltage
Protection
Each DMX output has super driving ability. Each input has LED indicator.
Cast aluminum material, weatherproof, UV resistant.
IP Rating: IP65.
Wide input stable electric power supply, suitable for voltage input of different countries.
Input Voltage: AC 88～256V 50/60Hz.
Dimension: 225mm×150mm×85mm.
Net Weight: 2.0Kg.
Up to CE standard, UL standard and GB 7000.15-2000 standard
| Weight | 3 kg |
|---|---|
| Dimensions | 42 × 21 × 16 cm |
| Input Voltage | AC 88～256V 50/60Hz. |
| Certification | Up to CE standard, UL standard and GB 7000.15-2000 standard |
| IP Rating | IP65. |
| Application | outdoor landscape lighting, roadside stage performance, waterfront event show, park theatrical show, open-air carnival, outdoor concert tour, scenic area illumination, courtyard party, exterior building lighting, rural festival stage |
