80KG DMX RDM Kinetic Stage Lifting Winch,0‑15M Stroke,4‑Channel

1000W Kinetic Stage Lifting Winch Hoist,Emergency‑Stop Overload Protection,Composite Power Signal Cable,Double Steel Wire Rope,Power‑Fail Position Memory For Events

This 80kg dmx rdm kinetic stage lifting winch is heavy‑duty vertical kinetic rigging device built for concert crews, tv studio technicians and global touring‑rental fleets. It offers 80kg maximum load capacity,0‑15 meters lifting stroke and average lifting speed at 0.5 m/s, supported by brake‑equipped servo motor and dual load‑bearing steel wire ropes. It features emergency‑stop trigger, overload protection and power‑failure position memory function. Equipped with color LCD operation panel and four menu setting buttons, it adopts DMX512 RDM communication protocol. Rated power reaches 1000W under AC200‑240V 50‑60Hz input. Composite cable transfers power up to 1.32kW plus Cat5e network signal. It supports max 2‑unit series daisy‑chain connection, vertical suspension installation with eagle‑claw light hooks, IP20 for indoor‑only application.

Many event rigging technicians and rental houses face real‑world pain‑points. Ordinary kinetic winches lack multi‑layer safety safeguards such as overload lockout or power‑fail memory. Some low‑grade units use single load‑bearing cables, bringing hidden risks for high‑value hanging lighting and screen equipment. The 80kg dmx rdm kinetic stage lifting winch addresses these B‑end rigging concerns with heavy‑duty servo‑driven kinetic lifting hardware for indoor immersive stage projects.shop‑category‑kinetic‑stage‑lifting‑winch‑rigging‑systems

Mechanical & Safety Highlights Of The 80Kg DMX RDM Kinetic Stage Lifting Winch

At mechanical core, the 80kg dmx rdm kinetic stage lifting winch adopts brake‑equipped servo motor paired with two independent load‑bearing steel wire ropes. It supports 80‑kilogram payload and delivers 0‑15‑meter adjustable lifting stroke at 0.5 m/s average lifting velocity.

Multiple safety protections are built‑in for live‑show risk reduction. Emergency‑stop circuit cuts movement instantly under abnormal conditions; overload protection triggers auto‑lock when payload exceeds rated capacity. Power‑failure memory preserves fixture height position after unexpected power cut, avoiding uncontrolled dropping incidents. Composite shielding cable transmits both power and signal for hanging stage loads. Installation requires vertical suspension with eagle‑claw hooks. This fixture is IP20 rated for indoor‑only deployment.

Control & Site Deployment For The 80Kg DMX RDM Kinetic Stage Lifting Winch

It implements DMX512 plus RDM industry standard protocol. RDM allows remote parameter reading and adjustment without climbing overhead truss structures. On‑site operators can also set parameters locally via integrated color LCD panel and four physical menu buttons.

Maximum two main units can be connected in series daisy‑chain for multi‑winch synchronized kinetic choreography. Composite cable supplies up to 1.32kW power plus Cat5e network or DMX512 signal for suspended lights and kinetic LED screens. Users should strictly follow payload limits and vertical‑mount requirements during rigging setup.

For rental‑house kinetic rigging inventory expansion and fixed installation for TV‑studio and cultural‑tourism venues, this 80kg dmx rdm kinetic stage lifting winch delivers high payload capacity, comprehensive safety interlocks, RDM remote control and composite power‑signal transmission. It provides B‑end rigging professionals a reliable vertical kinetic lifting solution for concert, studio and large‑scale indoor live‑event productions.

Specification
• Stroke (Lifting Height): 0‑15 meters
• Load Capacity (Lifting Capacity): 80kg
• Lifting Speed (Average): 0.5 m/s
• 4‑channel smooth lifting control
• Brake‑equipped servo motor
• Emergency stop function
• Overload protection function
• Power failure memory position function
• 2 load‑bearing steel wire ropes
• Composite Cable for Power Supply and Signal Transmission: Supports 1.32kW/220V + 1 Cat5e Ethernet cable (supplies 220V power and network signals or DMX512 signals to illuminants)
• Main Unit Material: Aluminum alloy, etc
• Main Unit Appearance: Black
• Main Unit Net Weight: 69 kg
• Main Unit Dimensions: 904*380*481mm (excluding light hooks)
• Protection Class: IP20

Control
• Color LCD control panel
• 4 menu buttons for function settings
• DMX512/RDM control protocol (Digital Multiplex 512/Remote Device Management)
• Brake‑equipped servo motor system with emergency stop function

Electrical Specifications & Interfaces
• Rated Voltage: AC200‑240V, 50/60Hz
• Rated Power: 1000W
• Supported Illuminant Power: ≤1.32kW (AC220V) (customizable to support 4kW (AC220V))
• Main Unit Power Input Interface: 1 pair of aviation power male & female connectors
• Maximum Connection Quantity: Maximum series connection quantity: 2 units
• Main Unit Signal Input Interface: 1 pair of XLR‑3 male & female sockets (for DMX512 signal interface controlling lifting)
• Emergency Stop Switch Interface: 1 pair of XLR‑4 male sockets (emergency stop signal interface)
• Through Signal Input Interface: 1 RJ45 connector, 1 pair of XLR‑3 male & female sockets
• Through Signal Output: 1 RJ45 connector
• Through Power Input: 1 aviation power male socket
• Through Power Output: 1 aviation power female socket

Installation
• Installation Requirement: Ensure vertical suspension;
• Installation Accessories: 4 pcs eagle‑claw light hooks for suspension mounting

Q1: What is load capacity,lifting stroke and lifting speed?

A1:Max 80kg load;0‑15 meters lifting stroke;average lifting speed 0.5 m/s,indoor IP20 usage only.

Q2: What core safety mechanisms does this kinetic winch include?

A2:Brake servo motor,emergency‑stop,overload protection,power‑failure position memory,dual steel wire ropes.

Q3: What control protocols and local operating components are available?

A3:Supports DMX512 RDM protocol;color LCD panel with four physical menu setting buttons.

Q4: What is the limit for series daisy‑chain connection?

A4:The maximum series connection quantity for main units is 2 units under AC200‑240V power supply.

Q5: What does composite cable accomplish for connected stage fixtures?

A5:Transmits up to 1.32kW AC power together with Cat5e network or DMX512 signal to hanging luminaires.

Q6: What installation requirements and mounting accessories are provided?

A6:Must install in vertical suspension mode;uses four eagle‑claw light hooks for truss hanging mounting.

Q7: What type of stage devices can this kinetic winch lift?

A7:Moving‑head lights,LED kinetic screen panels and qualified LED effect lighting arrays under 80kg load limit.

Q8: Which application scenarios suit this kinetic lifting winch best?

A8:Concert tours,TV broadcast studios,cultural‑tourism immersive shows,corporate events and touring‑rental projects.
