DMX512 2 Input 8 Output Splitter Switchable 1-In 8-Out Wide Voltage 88-256V High Voltage Isolation Professional Stage Signal Amp Distributor Wireless 2.4G 300m Transmission 2-In 8-Out DMX512 Signal Amplifier
• 2-in 8-out DMX distro, switchable to 1-in 8-out, full isolation, high voltage protection
• 2.4G wireless 300m, independent amp & LED per channel, stable signal
• 19″ 1U rack, XLR 3/5Pin, wide voltage, lightweight for easy install
• Ideal for stage, concert, wedding, club and professional lighting system
Price range: $150.00 through $860.00
DMX512 2 Input 8 Output Splitter Switchable 1-In 8-Out Wide Voltage 88-256V High Voltage Isolation Professional Stage Signal Amp Distributor Wireless 2.4G 300m Transmission 2-In 8-Out DMX512 Signal Amplifier
High Voltage Protection
Independent input and output signal (include earth cable of signal)
Separate signal amplifier system and individual LED light of each channel
Wide input stable electric power supply: AC88-256V
Light weight
DMX512/1990 Standard
Input/output: XLR Pin3 Optional:XLR Pin5
Eight-way DMX distributor with two input (It can be changed into a into eight out through the buttons)
Input Voltage: AC88~256V 50/60Hz
Dimension: 19″ 1U, 482mm×173mm×44mm
Net Weight: 2.01 Kg
Standard DMX512 signal; 2.4G wireless
DMX512 receiver
Communication distance:300m (visible distance)
| Weight | 4 kg |
|---|---|
| Dimensions | 63 × 24 × 12 cm |
| Standard DMX512 signal | 2.4G wireless |
| Input Voltage | AC88~256V 50/60Hz |
| Name | Eight-way DMX distributor with two input (It can be changed into a into eight out through the buttons) |
| Feature | High Voltage Protection |
| Communication distance | 300m (visible distance) |
